Date of Design

2009

Product

Apple Ipod Interface Board

Assembly ID

SC01

Company

ALTIUM

Function

Full Capability Ipod Interface

Primary Device

None (Discrete's)

Technology

5 track/5 space/28 via

PCB Build Specification

2 Layer, 1/2oz,  MASK, ENIG, TUC04

Design Compliance

IPC-A-600/IPC-6012/IPC-610

Manufacturer

Speedy Circuits (TAIWAN)

CAD Application

Altium Designer W09

Prototype Availability

Yes

Downloads

SCHEMATIC - SC01 (PDF)
The following designs comprise some of the electronic solutions I have created, implemented, prototyped and prepared for
Electronic designs by Steven Howell
         2009

manufacture. The index includes lab prototypes as well as final production units and examples of their application.


There are no classified military designs in this list.
