Date of Design

2016

Product

Summit Industrial Display

Assembly ID

SID01

Company

Summit Innovations

Function

FHD 1920x1080 LCD Display Unit

Primary Device

T-SUM-V59XUZ1

Technology

8 track/8 space/26 via

PCB Build Specification

2 Layer, 1oz,  MASK, HASL, FR4

Design Compliance

IPC-A-600/IPC-6012/IPC-610

Contract Manufacturer

Southern Stars Enterprises (China)

CAD Application

Altium Designer R14

Prototype Availability

Yes

Downloads

None
The following designs comprise some of the electronic solutions I have created, implemented, prototyped and prepared for
Electronic designs by Steven Howell
manufacture. The index includes lab prototypes as well as final production units and examples of their application.


There are no classified military designs in this list.


© Copyright 2016 - Images are not to be used without written permission
         2016
