Date of Design

1990

Product

Composite Video Isolator

Assembly ID

VIDEOISOv01

Company

SONEX (Sony)

Function

Isolate video from live chassis

Primary Device

None (Discretes)

Technology

10 track/10 space (no via)

PCB Build Specification

Single Layer, 1.6mm, HASL, FR4

Design Compliance

None

Manufacturer

Critech (TAS)

CAD Application

Macintosh Paint (Mac Plus)

Prototype Availability

Yes
