Date of Design

2017

Product

PTS + SMT Timing Systems

Assembly ID

UID021017

Company

Summit Innovations

Function

165Mhz VGA over UTP Driver

Primary Device

EL4543I + 24C02

Technology

10 track/6 space/24 via

PCB Build Specification

2 Layer, 1oz,  MASK, HASL, FR4

Design Compliance

IPC-A-600/IPC-6012/IPC-610

Manufacturer

General Circuits (China)

CAD Application

Altium Designer R17

Prototype Availability

Yes

Downloads

None
