Date of Design

2015

Product

Pure Timing System (PTS)

Assembly ID

SBA251015

Company

Summit Innovations

Function

Summit Backplate Assembly

Primary Device

NA

Technology

15 track/10 space/28 via

PCB Build Specification

2 Layer, 1oz,  MASK, HASL, FR4, SMOBO

Design Compliance

IPC-A-600/IPC-6012/IPC-610/FCC

Contract Manufacturer

General Circuits (CHINA)

CAD Application

Altium Designer R14

Prototype Availability

Yes

Downloads

None
The following designs comprise some of the electronic solutions I have created, implemented, prototyped and prepared for
Electronic designs by Steven Howell
manufacture. The index includes lab prototypes as well as final production units and examples of their application.


There are no classified military designs in this list.
